SOLID AS A ROCK…
Designed for hauling aggregates in severe off-road conditions, the quality, reliability and durability of our Contract Dumper is everything you’d expect from a Bailey trailer.
Our Contract Dumper is rock solid. The floor thickness increases per the size of trailer – 6 mm floor (4 tonne), 8 mm floor (6, 8, 10, 12, 14 tonne) and 10mm floor (17, 20 & 22 tonne). The RHS top chassis includes a RHS cross member and 4 mm sides (4 tonne), 6 mm sides (6, 8, 10, 12 & 14 tonne) and 8 mm (17, 20 & 22 tonne) with RHS frame.
A deep section box is fitted to withstand stone, concrete, rubble and other hardcore materials.
A heavy-duty RHS bottom chassis is mounted on a
heavy-duty tandem spring unit
ENQUIRE NOW
Ready to configure your Contract Dumper?
Find your preferred Bailey Trailers distributor using the dropdowns below – first choose your region, then select your dealer, and finally click ‘View Details’.
STANDARD FEATURES
✓ CD4-CD14 Independent hydraulic brakes
✓ CD17-CD22 Air brakes and load sensing
✓ Heavy-duty EN8 towing eye
✓ Parking brakes
✓ Hydraulic hose carrier
✓ Metal mudguards with flaps
✓ Front aggregate guard
✓ LED lights to RTA
✓ LED beacon
✓ Chromed rams
✓ Body prop
✓ Skid & skid carrier
✓ Anti-chip paint on headboard
✓ Hydraulic hose carrier
✓ Sprung drawbar CD17-CD22
SIZES / DIMENSIONS / TYRES
Model |
Capacity m3 |
LxWxH mm |
Loading height mm |
Tyres |
Axle(s) mm/stud |
Sprung d/bar |
CD 4 T |
3.25 |
3250x2350x500 |
1600 |
400/60x15.5 |
2x70/6 |
n/a |
CD 8 |
4.60 |
3445x2350x700 |
1800 |
12.5/80x15.3 |
2x70/6 |
n/a |
CD 10 |
5.30 |
3650x2500x700 |
1840 |
435/50 R19.5 |
2x90/8 |
Option |
CD 12 |
6.84 |
4050x2500x800 |
2135 |
385/65 R22.5 |
2xcom/10 |
Option |
CD 14 |
8.15 |
4660x2500x900 |
2210 |
385/65 R22.5 |
2xcom/10 |
Option |
CD 17 |
9.98 |
4960x2500x1000 |
2340 |
385/65 R22.5 |
2xcom/10 |
STD |
CD 20 |
12.33 |
5460x2500x1100 |
2440 |
445/65 R22.5 |
2xcom/10 |
STD |
CD 22 |
13.60 |
5960x2500x1100 |
2440 |
445/65 R22.5 |
2xcom/10 |
STD |
SHEETING SYSTEM
✓ Hydraulic Front to Back Sheet
DOORS
✓ Hydraulic Doors
LIGHTS
✓ Extra Flashing Beacon
✓ On/Off Switch for Flashing Beacon
✓ Reversing Lights and Mudflaps
✓ High Visibility Safety Strips
TOWING EYES
✓ Rear Towing Eye
✓ Towing Swivel Eye
✓ Scharmuller Hitch – Swivel
✓ Scharmuller Hitch – Cup Ball
✓ Scharmuller Hitch – Hitch Eye
SIDES AND FLOORS
✓ Extra Depth (75mm stages)
✓ Extra Thick Floor
✓ Extra Thick Sides
✓ Extension Sides
✓ Harder Wearing Flooring
GUARDS, BRAKES AND SUSPENSION
✓ Front Rubber Mudflaps
✓ Sprung Drawbar
✓ Air Brakes and Load Sensing
✓ Auto Slack Adjusters
✓ ABS Brakes
✓ Hydraulic Brake Load Sensing
✓ Air Suspension
MISCELLANEOUS
✓ Fold Up Trailer Skid (Shoe)
✓ Greasing Bank (Suspension and Axles)
✓ Hinged Rear Draw Bar (Hydraulic to Rear)
✓ Hinged Rear Draw Bar (Hydraulic and Air to Rear)
✓ Jack – Screw
✓ Jack – Hydraulic
✓ Jack – Hydraulic with Hand Pump
✓ Reversing Camera
✓ Storage Rack
✓ Twin Tipping Pipes
✓ Toolbox
✓ Electric / Hydraulic Weighing System
✓ Wooden Nudge Bar
✓ Wheel Nut Indicators
✓ Bespoke Colour
CLICK ON ANY IMAGE TO SEE A LARGER VERSION
CONTRACT DUMPER SPEC SHEET PDF
Download your Contract Dumper trailer specification sheet (featuring full CD drawings and additional technical information) as a PDF for easy offline viewing.
